Straight Traction Extension

Straight Traction Extension is used to adjust the level of the traction unit assembly and the patient's leg relative to the abductor bars.

Product Overview

Equipment Number: BF268

Used to adjust the level of the traction unit assembly and the patient's leg relative to the abductor bars. As pictured here, extension is in a position that lowers the patient's leg relative to the abductor bar for tibia/fibula nailing.

Other Attachments Required: Traction Unit Assembly (BF0006) and Traction Assembly Clamp (BF0002) Table Compatibility: 3080, 3085 with Orthopedic Extension, Ortho II, and OrthoVision tables

Usage: Lower extremity fractures

NOTE: Patient weight limitation is 300 pounds (136 kg) for OrthoVision & Ortho II tables. Patient weight limitation is 400 pounds (181 kg) for 3080/3085 tables and Ortho Extension.

REQUEST A QUOTE

Literature

BROCHURE
Document #	Document Title
M11339EN	SURGICAL TABLE ACCESSORIES CATALOG
M11339FR	SURGICAL TABLE ACCESSORIES CATALOG (FRENCH)
M11339FR	SURGICAL TABLE ACCESSORIES CATALOG
P150832316	CMAX/AMSCO 3085 SP/3080 ORTHOPEDIC EXTENSION SET-UP GUIDE (PDF ONLY; ORDER THROUGH CUSTOMER SERVICE)
P150832738	5085/4085 PATIENT POSITIONING INSTRUCTIONS QUICK REFERENCE GUIDE
P150832738EN-CA	5085/4085 PATIENT POSITIONING INSTRUCTIONS QUICK REFERENCE GUIDE (CANADA)
P150832738FR	5085/4085 PATIENT POSITIONING INSTRUCTIONS QUICK REFERENCE GUIDE (FRENCH)

SELL SHEET
Document #	Document Title
M3407EN	GAIN TRACTION WITH YOUR GENERAL SURGICAL TABLE ORTHOPEDIC EXTENSION

TECH DATA SHEET
Document #	Document Title
SD586	ORTHOPEDIC EXTENSION FOR CMAX AND AMSCO 3080/3085 SP SURGICAL TABLES
